Switch cabinet hygrostat, 40…90% r.H.

RFHSS-114.110/01

Switch cabinet hygrostat, 40…90% r.H.

Switch cabinet hygrostat designed especially for monitoring and controlling humidity in switch cabinets, drinks machines or ATMs.
  • Art.-Nr.: ZN275001

    Technical data

    Ambient temperature, lower value0 °C
    Ambient temperature, upper value60 °C
    Average power consumption0 W
    Bearing temperature, lower value-20 °C
    Bearing temperature, upper value80 °C
    ColourGrey
    Connection cross-section0,5 mm² – 2,5 mm²
    Depth46 mm
    Electric connectionScrew terminals
    External settingYes
    Height64 mm
    Housing materialPlastic PA6
    Humidify / dehumidify control functionYes
    Maximum air humidity (non-condensing)95 % r.H
    Maximum switching currentE: 5 (0,2) A ; B: 2 (0,2) A
    Maximum switching voltage230 V AC, 50 Hz
    MediumAir, not aggressive
    Minimum switching current100 mA
    Minimum switching voltage24 V AC / 50 Hz
    Mounting / attachmentOn supporting rails (35 mm), EN 60715
    Number of control ranges1
    Number of outputs2
    Operating voltageNone
    OperationRotary knob
    Output signalHumidify or dehumidify, switching
    Protection class0, determined by the assembly location
    RAL colour number (similar)7035
    Safety and EMCIn accordance with DIN EN 60730
    Sensor elementPlastic fibres
    Setting range, rel. air humidity lower value40 %
    Setting range, rel. air humidity upper value90 %
    Surface propertiesMatt
    Switching contactTwo-way contact
    Switching differenceApprox. 5% r.H.
    Switching elementMicroswitch
    Switching power1150 W bzw. 460 W
    Test mark approvalUL at 230 VAC
    Type of protectionIP30
    Width37 mm
    Circuit diagram Circuit diagram

    Downloads

    Instructions

    Datasheet

    PhotoTypeArticlenumberFeaturesKind
    JZ-13ZA990001Standard rail with drill holes for attaching switch cabinet controls, length 40 mmAccessories
